TB01 Blackbody

Accuracy in Temperature for Thermal Camera

    Blackbody - Accuracy in Temperature for Thermal Camera



    Blackbody is a calibration device and a standard temperature source. The thermal camera with blackbody can be

    calibrated in real time, which can keep the temperature measurement accuracy at a high level of ±0.1-0.3.



    Set Up Tips:

    - Keep the distance between target and camera about 2.5-3m;

    - The blackbody is used together with thermal camera,1.5-3m away from the camera, camera installation should be

      higher than the blackbody, and the top view angle is the best ;

    - Make sure that the blackbody would not be blocked by other targets during temperature measurement;

    - Recommend to set up the solution in a stable environment without wind in the indoor space.



    Features:

    · Working Temperature: 40.0(ambient temperature +5.0~ 50.0 adjustable)

    · Temperature Resolution: 0.01

    · Temperature Measurement Accuracy: ±0.2(temperature range 35-37, ambient temperature 23 ± 3)

    · Temperature Stability: ±0.1

    · Effective Emissivity: 0.97±0.02

    · Power:110V-220V AC;50Hz-60Hz

    · Operating Ambient Temperature/Humidity: ambient temperature 10-40,humidity ≤80%RH

    Model NO

    MP-TB01

    Effective Radiation Area

     80mm x 80mm

    Emissivity

     0.97 ± 0.02

    Temperature Range

     (Ambient temperature [$add]5) – (50)

    Temperature Resolution

     0.01

    Measuring Accuracy

     ± 0.2 (Temperature range 35-37, ambient temperature 23 ± 3)

    Temperature Stability

    ±0.1

    Operating Ambient

    Temperature/Humidity

     Ambient temperature 10-40

     Humidity ≤80%RH

    Power Supply

     110V-220V AC;50Hz-60Hz

    Power Consumption

     ≤80W

    Heating Process

    <15minutes

    Overall Size

     200x150x110mm

     Weight

     <2KG
