E1AQ400F-P

4MP Outdoor Explosion-proof IR POE Network Bullet Camera

Explosion-Proof · Anti-Corrosion · Anti-Impact · Atainless Steel 304 · Exd IIC T6 Gb/ExtD A21 IP68 T80℃ · ONVIF
    Products
     4MP Outdoor Explosion-Proof IR POE Network Bullet Camera
    · S265/H.265/H.264 Encoding,Saving Half Storage Capacity with Our NVR.
    · Adopts Atainless Steel 304, Explosion-Proof,Anti-Corrosion and Anti-Impact,suitable for All Kinds of Complicated Environments.
    · Exd IIC T6 Gb/ExtD A21 IP68 T80℃.
    · IR Distance 30m,Built-in 2PCS High Effiency Dot Matrix IR Array LEDs.
    · AI Human Detection and Tracking,Motion Detection,Fast Recognition and High Accuracy,Real-Time Alert Push.
    · ￠160mm x 280mm (length),6.5Kg
    Model Number E1AQ400F-P
    Camera
    Image Sensor 1/2.8" low illumination CMOS sensor
    Min. Illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
    Shutter Time Auto(1/5 - 1/100000)
    Lens
    Lens Type 3.6mm Lens @ F1.6
    Lens Resolution 5MP
    Illuminator
    Light Distance IR Light 25~30m
    IR LEDs 3pcs IR Array LEDs
    Day/Night Infrared Mode: B/W
    Video
    Max. Image Resolution 4MP(2560x1440)@25fps
    Video Compression S.265/H.265/H.264
    Frame Rate Main Stream:4MP(2560x1440)@25fps,3MP(2304x1296)@25fps,2MP(1920x1080)@25fpsSub Stream:D1(720x576),864x480,VGA((640x360),Q720P(640x360),CIF(352x288), 320x240
    Video Bit Rate 16Kbps-8000Kbps support self-adjustable as needed
    Image Settings Brightness,contrast,saturation,sharpness,chroma
    White Balance Auto / Manual
    Gain Control Support
    BLC Support
    HLC Support
    WDR Digital WDR (Off/Low/Middle/High)
    Noise Reduction 3D NR (Off/Low/Middle/High)
    Mirror Off/horizontal mirror/vertical mirror/180° flip
    Character Overlay(OSD) Multi-line OSD with title, time & date overlay — customizable colors.
    Audio
    Audio Input No
    Audio Output No
    Network
    Network Interface 1*RJ45 10M/100M Self-adaptation Ethernet Port
    Networking Protocol TCP/IP,UDP,HTTP,HTTPS,DHCP,RTSP,DDNS,NTP,PPPOE,UPNP,SMTP,RTMP
    Connection Protocol ONVIF,Slink,GB28181(option)
    APP Through the NVR
    PC Support
    Web Access Support HTML5 remote login operation(Free plug-in)
    Preview Simultaneously Video Number 2
    Device Abnormal Inspection Support network broken alarm, IP conflict alarm, illegal visiting alarm
    Security Mode Authorized user name and password,HTTPS encryption,AES connecting encryption, RTSP vertification
    Event
    Alarm Motion Detection Alarm, AI Humanoid Detection and Tracking Alarm
    Linkage Upload to FTP, Upload Picture, send email, trigger recording, trigger capture,Arming time support 24h arming/ night arming /customized arming
    Basic Event
    Motion Detection Set detection area,can set multi-level sensitivity
    Privacy Mask Alarm Support 1 area
    Privacy Mask Support 4 area
    Smart Event
    Human Detection It can detect target ≤5-10 persons at the same time
    Humanoid pixel ≥40X40
    Detection Ratio ≥99%(meet above requirement)
    Capture Corresponding Speed ≤1s
    Support specified area detection, default full screen
    Error detection rate 2% or less
    Maximum detection frame rate is 5fps /s
    Detection Part: people with any posture including half body,head,hand shoulder
    Detection Mode:support static and dynamic humanoid detection
    Interface
    Ethernet Interface 1 RJ45 10M/100M self-adaptive Ethernet port
    On-Board Storage No
    Alarm No
    RS-485 No
    Reset No
    General
    Explosion-proof ExD IIC T6 Gb/ ExtD A21 IP68 T80℃
    Protection Grade IP68
    Shell Material High-quality 304 Stainless Steel with polished surface, explosion-proof, dustproof, waterproof.
    Power Supply DC12V±10% /POE
    Power Consumption Max 10W
    Surge Protection 6KV
    Working Temperature -10 °C to 50 °C
    Working Humidity 0%-90% (Non-condensing)
