50D Face Recognition Camera

4K 5MP Face Recognition Sentrust Bullet Camera with SenseTime Algorithm

5MP · Efficient H.265+ Compression Technology · 3.6/6/8mm Lens · Excellent Low-light Performance · Built-in intelligent deep learning face algorithm, extracts target features by itself, and forms deep face images for learning · Support up to 32 face detection per frame,100000 face records,and 50000 face databases · POE

    Products
      FEATURE

    · 1/2.8" 5MP low illumination CMOS sensor.

    · 3.6/6/8mm fixed lens.

    · Embeds a deep-learning facial algorithm that autonomously extracts features and generates high-quality, learnable face data.

    · Support Face Recognition,support 50,000 face libraries,100,000 facial records,Up to 32 faces detectable per frame.

    · DC12V / POE,DWDR,HLC,BLC,White Balance,Defog,3D DNR,IP66 Waterproof.


      APPLICATION
      Facial recognition surveillance cameras are widely used in scenarios that enhance security, management efficiency, and automation.
    · Security Monitoring:
       - Managing access to important places such as airports, train stations, ports, warehouses, factories, etc., by identifying unauthorized or suspicious individuals.

    · Public Safety:
      - Recognizing suspicious persons or wanted suspects on city streets, squares, public transportation systems, thereby enhancing public safety.

    · Access Control:
      - Automatically recognizing and allowing authorized personnel to enter corporate buildings, company parks, government agencies, campuses, etc.

    · Financial Institutions:
      - Used in banks, ATMs, stock exchanges, for identity verification and surveillance to prevent fraud.

    · Retail and Commercial:
      - Recognizing loyal customers or potential shoplifters in shopping malls and supermarkets to improve customer experience and security.

    · Event Tracking and Investigation:
      - Tracking suspects or missing persons, providing evidence for police investigations.

    · Traffic Management:
      - Recognizing vehicles and drivers on highways, toll gates, or parking lots for automatic access and increased efficiency.

    · Airport and Station Security:
      - Automatically verifying passenger identities to enhance security checks.

    · Campus Management:
      - Controlling access, managing student vehicles, and campus security patrols.

    · Large Event Security:
      - Recognizing potential risk individuals at conferences, sports events, concerts, and other large gatherings.

     Model Number

    50DAI50F-PBR-FC

    System

    Image Sensor

    1/2.8" CMOS High Performance Sensor

    Min. Illumination

    Color: 0.001Lux @F1.0, B/W: 0.001Lux@F1.0

    Lens

    Lens Type

    3.6mm fixed Lens@F1.6

    Lens Resolution

    5MP

    Illuminator

    Light Distance

    IR Light 30m

    IR LEDs

    Infrared mode (Full color optional, need to request when placing order)

    Day & Night Mode

    Default Infrared Mode

    Video

    Max. Image Resolution

    5MP(2592x1944)@25fps

    Video Compression

    H.265[$add]/H.265/H.264

    Frame Rate

    Main Stream: 25fps: 2592x1944,2560x1440

    Sub-Stream: 25fps:704x576

    Video Bit Rate

    512Kbps~32Mbps

    Character&Watermark Overlay

    Support

    AIISP

    Support AIISP Image Enhancement

    Gain Control

    Support

    BLC

    Support

    HLC

    Support

    Defog

    Support

    WDR

    Digital WDR, 120 dB

    Noise Reduction

    3D NR/2D NR

    Anti-flicker

    Support

    Lens Correction

    Support

    Mirror

    Support

    Electronic Shutter

    1/12s-1/100000s

    Audio

    Audio Input

    NO

    Audio Output

    NO

    Network

    Network Connection Mode

    Wired

    Networking Protocol

    CGI,HTTP,HTTPS,GB28181,SIP,RTMP,TCP/IP,UDP,RTP,FTP,RTCP,RTSP,NTP,DHCP,DNS,DDNS,SNMP,SSL/TLS,Websocker etc.

    ONVIF

    Support

    Web Access

    With plugin preview: IE10, IE11

    Plugin-free preview: Edge, Chrome, Firefox, etc.

    Simultaneous Preview Number of Channels

    8

    Face Capture and Recognition

    Face Catpure Mode

    Supports multiple face capture modes: Instant, Interval, and Post-departure.

    The number of captures is configurable.

    Face Capture Recognition Priority Mode

    Face Capture Recognition Priority Mode with real-time name overlay from

    the face database on the main stream OSD.

    Face Management

    Support white list, black list, VIP list management

    Face Capture Scenes Configuration

    Backlight environment, normal environment

    Face-Recognition Records/Databases

    Support up to 32 face detection per frame,100000 face records,and 50000 face

    databases

    Face Recognition Algorithm

    Built-in intelligent deep learning face algorithm, extracts target features by itself,

    and forms deep face images for learning

    SDK

    Provided SDK development kit, support secondary development, support CGI,HTTP,WEBSOCK protocol integration

    Interface

    Ethernet Interface

    1 RJ45 10M/100M self-adaptive Ethernet port

    On-Board Storage

    No

    Alarm

    YES

    Audio

    No

    RS-485

    YES

    Reset

    No

    General

    POE

    IEEE802.3af

    Power Supply

    DC12V±10% /POE

    Power Consumption

    <10W

    Surge Protection

    6KV

    Housing

    Metal Dome

    Weather Proof

    IP65

    Working Temperature

    -20 °C to 60 °C

    Working Humidity

    10%-90% (Non-condensing)
