Products

· 433MHz wireless, stable and strong anti-interference.

· 80m long-distance transmission in open area.

· Low power consumption, long battery life.

· Pet-friendly design, avoids false alarms under 15kg.

· 12m detection distance & 110° wide detection angle.

· Wide working temperature: -10℃~50℃.

· Easy wall-mounted installation with bracket.

· Durable ABS material, solid and reliable.

· Simple battery-powered design (3×AA 1.5V).

· Compact size, modern white appearance.

Model Number	AL-P01
Wireless Frequency	433MHz
Transmitting Distance	80m (Open Area and No Interference)
Wireless Transmitter Code	EV1527
Power Supply	1.5V AA Battery x3
Standby Current	<15uA
Alarm Current	<25mA
Pet Immunity	<15kg
Detection Scope	<12m/110°
Working Temperature	-10~50℃
Working Humidity	5%--95% non-condensing
Installation	Wall-mounted
Material	ABS Plastic
Color	White
Dimension	1406745 mm
Weight	170g
Package Included
PIR Sensor	1PC
User Manual	1PC
Bracket	1PC
Screw Bag	1PC
