AL-S01R-Mapesen Technology Limited CCTV Security Camera Factory

Products

· 433MHz wireless transmission, stable signal.

· 80dB loud audio alarm for fire warning.

· Ultra‑low standby current for long battery life.

· LED status indication: normal, alarm, low battery.

· Low battery reminder ensures safe use.

· Wide working environment: -10℃~50℃.

· Wall‑mounted installation, no wiring needed.

· High‑quality ABS material, durable.

· Compact size, elegant white outlook.

· Easy to use and maintain.

Model Number	AL-S01R
Wireless Frequency	433MHz
Wireless Transmitter Code	EV1527
Power Supply	One 9-Volt Battery
Standby Current	<10uA
Audio Alarm	80dBA@10ft
RF Output Power	10dBm
RF Modulation	ASK
LED Status	Smoke Alarm/Test: Flashing continuously/Beep Rapidly
	Standby: Flashes at 45-second intervals.
	Low Battery: Flashes and emits a short beep every 45 seconds.
Working Temperature	-10~50℃
Working Humidity	10%~95% Relative Humidity
Installation	Wall-mounted
Material	ABS Plastic
Color	White
Dimension	11050110 mm(include package)
Weight	170g(include package)
Package Included
Smoke Detector	1PC
User Manual	1PC
Installation Screw Bag	1PC
