TUYA-7002-WIFI

Fire Prevention Flame Detector

Tuya Smart · Flame Detection · Detection Distance >10m · 2.4G WiFi · Siren Alarm · APP Alarm Push · Easy Installation
    Products
    · Fire Prevention Flame Detector
    · Working Voltage: 5V1A
    · Rated Power: 0.2W
    · Detection Distance: >10 meters (10cm*10cm area visible flame)
    · Installation Height: 1.5m-3m
    · WiFi Frequency: 2.4G wifi
    · Normal Working: The red LED flashes every 7seconds.
    · Alarm Indication: Red led always on
    · Working Temperature: -5 ° C - +60 ° C
    · Operating Humidity: ≤95% (no condensation)
    · Spectral Response range: 180nm~ 290nm
    · It detects fire by monitoring the ultraviolet light ced by burning substances, and is suitable for
      places proneo visible flames, strong flame radiation, or where there is no shadowy igition stage.
    · When a fire occurs, the device will sound the siren in the first instance and push the alarm message
      to the cell phon through the APP.
    · Support the creation of intelligent scenes, linkage control with other TUYA products.
    Model Number TUYA-7002-WIFI
    Product Overview
    This product is a UV flame detector that detects fire by detecting the ultraviolet rays generated by the burning substance. It would sound alarm and push message to user APP as soon as there is a fire occurring It is suitable for places that are prone to have visible flames and have strong flame radiation or no smoldering stage in the event of fire. This device could be used to detect fires and reduce losses in a timely manner.
    Technical Parameters
    Working voltage 5V 1A
    Rated Power 0.2W
    Detection Distance >10 Meters (10cm*10cm area visible flame)
    Installation Height 1.5m - 3m
    WiFi Frequency 2.4G WiFi
    Normal Working The red LED flashes every 7seconds
    Alarm indication Red led always on
    Working Temperature -5℃~60℃
    Operating Humidity ≤95% (no condensation)
    Spectral Response Range 180nm~ 290nm
    Dimension 130mmx59mmx67mm
